Elo ESY22i5 I-series 22'' Interactive Touchscreen Display E222794 USED

Elo ESY22i5 I-series 22'' Interactive Touchscreen Display E222794 USED

$625.75

Sold Out

Description

Part Number(s)

PCAP i5 Win7 (Worldwide) - E222794
PCAP i5 Win10 (Worldwide) - E971081

Enclosure Color

Black

Touch Technology & Capacity

PCAP (TouchPro® Projected Capacitive) - 10 Touch

Processor

i5: Intel i5 2.3GHz (up to 3.3 GHz) 6500TE Quad-Core Processor; 6MB Smart Cache

Graphics

i5: Intel HD Graphics 530

BIOS

AMI

Memory (RAM)

i5: 4GB DDR4 SODIMM on 1 of 2 slot (Expandable to 16GB)
NOTE: Maximum memory using 2 available slots; Replaceable up to 16GB maximum, SODIMM DDR4-2133

Storage

128GB 2.5" 7mm SATA SSD, 72 TBW

Diagonal Size

21.5'' diagonal, Active matrix TFT LCD (LED)

On-Screen Display (OSD)

Power, Brightness Up, Brightness Down, Volume Up, Volume Down

Aspect Ratio

16:9

Active Area (mm)

18.6" x 10.5" / 476mm x 267.8mm

Resolution

Full HD 1920 x 1080 @ 60Hz

Number of Colors

16.7 million

Brightness (typical)

LCD Panel: 250 nits
PCAP: 225 nits

Response Time-total (typical)

30 msec

Contrast Ratio

3000:1

Viewing Angle

Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total

AV Capability

Front-facing HD webcam
Stereo speakers

Webcam

Max resolution: 1920 x 1080 30fps (MJPEG)
Auto Focus @ 10cm ~ Infinity
Automatic Exposure Control
Automatic White Balance Control
Automatic Gain Control

USB Ports

i2: 2 x USB 3.0, 3 x Micro USB for Elo peripherals
i5: 4 x USB 3.0, 3 x Micro USB for Elo peripherals

Ethernet Port

1 x LAN RJ45 (Gigabit)

Wireless

Wi-Fi 802.11 a/b/g/n/ac

Bluetooth

Bluetooth 4.0

Additional Video Out

2nd Micro HDMI out

Audio Ports

1 x 3.5mm line out

Speakers

Two 2W internal speakers

OS

Windows 7*

Languages

Windows 7 - 35 Language groups

Power

Maximum output power: 90W (Max Draw: 100W)
Maximum output power: 150W (Max Draw: 170W)

Power Supply

External 19VDC universal-type power supply brick

Input Voltage

100 - 240 VAC 50/60Hz

Power Consumption (Typical)

i5: 90.63 W

Dimensions

20.6" x 12.76" x 1.8" / 524mm x 324mm x 45mm

Shipping Box Dimensions

26.97" x 19.41" x 7.09" / 685mm x 493mm x 180mm

Weight (Unpackaged)

12.05 lbs / 5.47 kg

Weight (Packaged)

17.65 lbs / 8.03 kg

Operating Temperature

0°C to 35°C / 32°F to 95°F

Storage Temperature

-20°C to 60°C / -4°F to 140°F

Humidity

Operating: 20% to 80%
Storage: 5% to 95%

Regulatory approvals and declarations

UL/cUL, FCC, TUV, CB, CE, VCCI

Real-Time Clock

lithium-ion battery

MTBF

50,000 hours demonstrated

Mounting Options

VESA - 75mm x 75mm and 100mm x 100mm
Wall/pole mount or secure base to tabletop/desktop

Sealability

Touchscreen sealed to sub-bezel
Touchscreen sealed to LCD

Power Cables

Power Cables Included

What's in the Box

Windows I-Series Touchcomputer
US Power Cable

Upgrade Options

320GB 5400 rpm Hard Disk Drive (HDD) - Elo P/N: E274069

Replacement DC Power Supply

i2 - 19V DC power brick (90W) - Elo P/N: E395155
i5 - 19V DC power brick (150W) - Elo P/N: E059701


Typically ships within 48 hours
